RAM Mounts

$90.00

In stock

Device holder: tablets 217–284 mm wide.

RAM ball size guide

The letter in a RAM part number is the ball size. Every part in a mount must use the same ball size. C size parts carry no letter, so RAM-201U is a C size arm and RAM-B-201U is the B size version.

SizeBall diameterHolds up toBest for
A9/16" (14 mm)0.45 kgSmall cameras, action cams, remotes
B1" (25 mm)0.9 kgPhones, GPS units, small tablets. The most common size.
C1.5" (38 mm)1.8 kgTablets, small monitors, rugged devices
D2.25" (57 mm)2.7 kgLarge displays and laptops
E3.38" (86 mm)6.8 kgHeavy monitors and equipment

Arm length sets the reach. Short keeps the device close and rigid, Medium suits most installs, Long is for extra reach. If in doubt, choose Medium.

Not sure this fits your setup?Tell us your device and where you are mounting it. The RAM® Mount Builder shows every mount that fits.Find my mount
SKU RAM-234-6 Categories ,
Overview

Overview

Well thought out and compact designs are common place at RAM and our new RAM Tough-Tray™ II is no exception. Spring loaded to create just the right amount of holding force, most tablets, UMPC’s, and compact laptops can be made safe and secure while on the go. Simple to install and adjust retaining arms insure a perfect fit without interfering with ports or functions. Also, if a compact laptop is in place, these retaining arms hold firm with the screen up or down. Ideally suited to a multitude of applications, and easily attached to hundreds of mounting systems for cars, boats, planes, and more, compact devices just work better in the universal tablet holder from RAM.

Features

  • Spring-loaded universal laptop and tablet holder
  • Includes a variety of clamping arms to keep your device secure
  • Made of high-strength composites for durability and reliability in the most demanding environments
  • Backed by a lifetime warranty

Specs

Hardware Included

Tray Assembly Hardware
(4) #8-32 x 5/8" Machine Screws
(4) #8-32 Nylock Nuts

Tray Dimensions

Width Range: 8.56" - 11.2"
Side Arm Clamp Height: 2.75" max
Tray Depth: 6"
Tray Thickness: 1"

Hole Pattern

4-Hole AMPS: 1.181" x 1.496"

Materials

High strength composite

Packaging Type

Poly Bag

Weight

1.15 lb
