RAM® X-Grip® with Dual Suction for 9″-11″ Tablets – Inset Plate

RAM® X-Grip® with Dual Suction for 9″-11″ Tablets – Inset Plate

OVERVIEW

The RAM-B-189-UN9-ALA1-KRU consists of a double 3.3" twist lock suction cup base, double socket arm, extended retention knob and universal X-Grip® cradle for 9"-11" Tablets. Included are extra easy access grip knobs, located on the back of the cradle for quick release of your tablet. The RAM-B-189-UN9-ALA1-KRU expands and contracts for perfect fit of most 9"-11" tablets with or without sleeves, as well as some smaller tablets. Please verify dimensions of your tablet below for compatibility with the X-Grip®. The X-Grip® cradle is compatible with handheld devices that will fit the dimensions listed below. It is important to verify the dimensions of your handheld device with a case/sleeve/skin when determining the overall size.

HARDWARE INCLUDED

Assembly Hardware

HOLDER DIMENSIONS

Max Height: 10.25" (using optional supports)Width Range: 6.25" - 8.1"Max Depth: .875"

SUCTION SIZE

(2) 3.3" Diameter Bases, Total Width 7.95"

SOCKET TO SOCKET LENGTH

3"

BALL SIZE

B Size (1")

WEIGHT CAPACITY

Standard Use: 2 lbsHeavy-Duty Use: 1 lb

MATERIALS

Powder coated steelMarine-grade aluminumHigh strength composite

PACKAGING TYPE

Poly Bag

WEIGHT

2.55 lb

ADDITIONAL INFORMATION

*The rubber material used in suction cups is considered a general wear item and is not covered under the lifetime warranty. Learn more about the RAM® warranty policy here.
