RAM® Heavy Duty C-Clamp Base For Ball Bases & Pedestal Mounts

RAM® Heavy Duty C-Clamp Base For Ball Bases & Pedestal Mounts

OVERVIEW

The RAM® Heavy Duty C-Clamp Base For Ball Bases & Pedestal Mounts (RAM-CC1U) is a rugged, steel clamp mount designed for flexible, non-permanent device installation across a wide variety of workspaces. Ideal for desks, tables, carts, or mobile stations, this clamp secures firmly to surfaces ranging from 0" up to 4" in thickness—no minimum edge depth required. Built for durability, the all-steel construction delivers long-lasting performance, while the padded interior safeguards mounting surfaces from scuffs or scratches. Whether in industrial settings or professional offices, this clamp provides a secure hold without compromising aesthetics. This heavy-duty desk clamp features three integrated mounting hole patterns on its top surface; 4-hole AMPS for B size or C size RAM® ball bases, custom pattern for GDS® pedestal docks, and custom pattern for RAM® D size bases. Additionally, a 4-hole AMPS pattern is located on the side of the clamp, providing a convenient mounting point for smaller mounting solutions like phones, tablets, scanners, and more. With its durable construction and multiple compatibility options, this C-clamp base supports everything from lightweight tablet mounts to heavy-duty docking stations. The tool-less adjustment knob allows for fast installation and easy removal, making it perfect for temporary workstations, demo stations, or environments where adaptability is key.

HARDWARE INCLUDED

Assembly Hardware(4) #8-32 x 3/8" Screws(4) 1/4"-20 x 3/8" Screws(4) 1/4"-20 Nylock Nuts(4) #8-32 x 5/8" Screws(4) Nylon Spacers

CLAMP RANGE

0" - 4"

HOLE PATTERN

4-Hole AMPS: 1.181" x 1.496"

MATERIALS

Powder coated steel

PACKAGING TYPE

Poly Bag

WEIGHT

2.35 lb
