GDS® Modular 10-30V Hardwire Charger with Type-C 2.0 Cable

GDS® Modular 10-30V Hardwire Charger with Type-C 2.0 Cable

OVERVIEW

The GDS® Modular 10-30V Hardwire Charger with Type-C 2.0 Cable (RAM-GDS-CHARGE-USBC-V7B1-1U) connects to a power source and provides power to any GDS® vehicle solution. When it comes time to upgrade, the quick disconnect feature enables you to avoid any rewiring by unplugging the power connector and attaching the new charger components. Compatible with any 5V device with a current requirement of 2.5A or less. Always Protected. Always Connected.®

HARDWARE INCLUDED

(1) USB Type-C to Type-A 2.0 Cable

PACKAGING TYPE

Poly Bag

INPUT VOLTAGE

10-30VDC

OUTPUT VOLTAGE

5-9VDC*

OUTPUT CURRENT

2.5A max

INPUT CONNECTOR

USB Type-C

INPUT CABLE LENGTH

1.2 Meters including 2 Pole Flat Marine Connector

OUTPUT CABLE LENGTH

.2 Meter

OPERATING TEMPERATURE

-10°C to +70°C

STORAGE TEMPERATURE

-40°C to +70°C

REGULATORY

Over Voltage ProtectionShort Circuit ProtectionReverse Polarity ProtectionRoHS ComplianceWEEE ComplianceSAE J-1113-5 Load Dump (Transient Voltage)Moisture ResistantFCC, CE, UKCA, IC

CERTIFICATIONS

E-Mark CertificationRCM CertificationIEC/UL 62368-1

WARRANTY

3 year warranty

WEIGHT

0.51 lb

ADDITIONAL INFORMATION

*5V output is by way of USB 2.0 BC1.2 and DCP mode. 9V output is by way of AFC and QC 2.0. To determine which hardwire charger is most suitable for your application, please see Hardwire Charger Compatibility Guide.
