RAM Tab-LockLocking Holder for 8″ Tablets

RAM Tab-LockLocking Holder for 8″ Tablets

OVERVIEW

The RAM® Tab-Tite™ spring-loaded, quick release holder offers a secure fit with easy access to the mounted tablet. The spring-loaded design makes it easy to insert and remove your tablet, while keeping it secure in a variety of applications. The custom end cups are designed to optimize the functionality of your tablet, enabling access to all buttons, ports, and tablet functions. Included is a set of four nuts and bolts to attach the holder to any RAM® components that contain the universal AMPS hole pattern. For off road environments and use in open cockpit applications, we recommended the use of a tether to assist in securing your device. The RAM® Tab-Tite™ holder is compatible with any tablet within the listed dimensions. In addition to most 8" tables with a cases, this holder can also accommodate the Samsung Galaxy Tab A 10.1 (2019).

HARDWARE INCLUDED

Assembly Hardware(2) #8 x 5/8" Sheet Metal Screws(2) M4 x 32mm Machine Screws(2) M4 Nylock Nuts(2) Keys

HOLDER DIMENSIONS

Height Range: 8.25" - 11"Width Range: 5" - 5.88"Depth Range: .3" - .67"

HOLE PATTERN

4-Hole AMPS: 1.181" x 1.496"

MATERIALS

High strength composite

PACKAGING TYPE

Poly Bag

WEIGHT

1.23 lb
